kód produktu: 4711636234283

ASUS P13R-E Intel C266 LGA 1700 ATX

ASUS P13R-E Intel je základná doska na stavbu alebo upgrade stolného počítača. Poskytuje zostave stabilný základ pre procesor, pamäť, úložisko a rozširujúce karty. Údaje základnej dosky zahŕňajú socket LGA 1700, typ pamäte DDR5-SDRAM a formát ATX.

Charakteristika
Internal I/O | 12V power connector
Yes
Rear panel I/O ports | VGA (D-Sub) ports quantity
1
Memory | Number of memory slots
4
Internal I/O | Number of chassis fan connectors
6
Operational conditions | Storage temperature (T-T)
-40 - 70 °C
Internal I/O | Front panel connector
Yes
Network | Ethernet LAN
Yes
Weight & dimensions | Depth
244 mm
Features | Cooling type
Passive
Network | Wi-Fi
No
Memory | Supported memory types
DDR5-SDRAM
Memory | Memory slots type
DIMM
Processor | Supported processor sockets
LGA 1700
Features | Component for
Server
Packaging data | Package height
78 mm
Other features | Weight
800 g
Packaging data | Package depth
281 mm
Internal I/O | TPM connector
Yes
Rear panel I/O ports | USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
4
Weight & dimensions | Width
305 mm
Storage controllers | Number of HDDs supported
8
Operational conditions | Operating temperature (T-T)
10 - 50 °C
Processor | Compatible processor series
Intel® Pentium®, Intel Xeon E, AMD Turion X2 Ultra Dual-Core, Intel Xeon 6300
Internal I/O | Number of COM connectors
1
Internal I/O | Chassis intrusion connector
Yes
Rear panel I/O ports | Ethernet LAN (RJ-45) ports
2
Rear panel I/O ports | USB 2.0 ports quantity
2
Expansion slots | Number of M.2 (M) slots
2
Packaging data | Package width
341 mm
Internal I/O | USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
Operational conditions | Storage relative humidity (H-H)
20 - 90%
Processor | Processor manufacturer
Intel
Memory | Supported memory clock speed (max)
4400 MHz
Storage controllers | Number of storage drives supported
10
Weight & dimensions | Height
68 mm
Graphics | Parallel processing technology support
Not supported
Features | Power source type
ATX
Processor | Processor socket
LGA 1700
Internal I/O | ATX Power connector (24-pin)
Yes
Internal I/O | EPS power connector (8-pin)
Yes
Memory | Memory channels
Dual-channel
Packaging data | Package weight
1.5 kg
Network | Ethernet interface type
Gigabit Ethernet
Expansion slots | PCI Express x16 (Gen 5.x) slots
1
Expansion slots | PCI Express x4 (Gen 4.x) slots
2
Expansion slots | PCI Express x8 (Gen 5.x) slots
1
Memory | Maximum internal memory per slot
32 GB
Memory | ECC сompatibility
ECC
Expansion slots | 2nd M.2 largest key size
22110
Internal I/O | Number of EPS power connectors (8-pin)
1
Expansion slots | 2nd M.2 highest PCI Express generation
4.0
Expansion slots | 1st M.2 largest key size
22110
Expansion slots | 1st M.2 highest PCI Express generation
4.0
Storage controllers | Supported storage drive types
HDD & SSD
Storage controllers | Supported storage drive interfaces
PCI Express 4.0, SATA III
Features | PC health monitoring
Fan, CPU, Temperature
Internal I/O | USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
Features | Motherboard chipset
Intel C266
Features | Motherboard chipset family
Intel
Features | Product colour
Black
Memory | Supported memory clock speeds
4000, 4400 MHz, 3600
Memory | Maximum internal memory
128 GB
Features | Motherboard form factor
ATX
Internal I/O | Number of SATA III connectors
8
Internal I/O | USB 2.0 connectors
1
